Wilson Bohannan Lock Company
Padlocks

  General Purpose

Weatherproof Solid Brass Padlocks Made To Last a Lifetime.

  High Security

Double Ball padlocks. Highest Resistance to Pulling and Prying.

  Interchangeable Cores

Lost Key? Personnel Change? IC Padlocks Re-key in Seconds.

  Door Key Compatible

Convenience and Control. One Key for Your Doors and Padlocks.


Cylinders

  Rim and Mortise

Cylinders Adaptable to OEM Keyways To Integrate or Create Keying Systems.


Special Features

  Custom Identification

Customize Your Padlock With Name, Logo or Whatever You Want.

  Lockout/Tagout

Wide Variety of Safety Lockout Products.

  Color Coding

Quickly ID Department Locks. Wide Variety and All OSHA safety colors.

  Accessories

We Have Just About Every Padlock Accessory There Is.

  Master Keying

Unique Keys for Multiple Padlocks; One Master Key to Open Them All.

  Keys

Factory Cut Keys For Your WB Padlocks. Or Blanks For Local Duplication.

Ordering Information
IC Core Padlocks

Phone - 800-382-3639
Fax - 740-383-1653
Email - wbco@padlocks.com
Mail - 621 Buckeye St. Marion, OH 43302

The Parts of an IC Padlock for Model Numbering

How to Read WB Interchangeable Core Model Numbers

Typical Five Digit Model Number -
 Series Number
 Shackle Clearance
 Shackle Material
1=Brass
2=Case Hardened Steel
3=304 Stainless Steel
5=416 Hardened Stainless Steel
 Accessories
0 = None
1 = 9" Steel Chain Attached to Body
2 = 9" Steel Chain Attached to Shackle
3 = 9" Brass Chain Attached to Body
4 = 9" Brass Chain Attached to Shackle
5 = 15" Brass Chain Attached to Body
6 = 15" Brass Chain Attached to Shackle
7 = Brass ID Tag Attached to Body
8 = Brass ID Tag Attached to Shackle
9 = Enameled Aluminum Tag Attached to Body
A = Enameled Aluminum Tag Attached to Shackle

FOR ADDITIONAL ACCESSORIES, PLEASE CONTACT FACTORY.

PLEASE ADD THE FOLLOWING WHEN PLACING AN ORDER FOR INTERCHANGIBLE CORE PADLOCKS:

1) Add "KR" to the model number if you want to add the Key Retaining Option.

PLEASE SPECIFY THE FOLLOWING WHEN PLACING AN ORDER FOR CORES

2) Specify 6 or 7-Pin Core

3) Specify Keyway Profile

4) Specify Core Finish: Satin Brass (#4) or Satin Chromium Plated (#26D)

Additional Information

Minimum order one dozen.

For special shackles please call.

Lubricate padlocks with powdered graphite.
